Lovibond Tintometer Senso Direct SD 335 Multi (Set 3) - pH/Con/DO

Waterproof handheld meter for the simultaneous determination of pH, temperature and either conductivity/TDS/salinity or dissolved oxygen

Part Number 724820



Highlights

• Intuitive user interface with graphical LCD-display
• Galvanically isolated measuring inputs
• Data transfer via Micro-USB in CSV format
• Robust protective armouring with two electrode holders

Portable multiparameter handheld meter for the simultaneous determination of pH, temperature and conductivity or dissolved oxygen. The combination of user-friendly operator guidance and graphic LCD display makes the meter the ideal companion for daily on-site analysis of water.



Applications

• Boiler Water
• Cooling Water
• Drinking-Water Treatment
• Pool Water Control
• Pool Water Treatment
• Waste Water Treatment



Modern Technology

• Due to galvanic isolation the temperature and two other parameters can be determined and displayed simultaneously.

Intuitive Handling

• The combination of user-friendly operation and graphic LCD display in 7 different languages makes the portable measuring instrument the ideal companion for daily use in water analysis.

Data management

• Measurement data including time stamp and location ID can be recorded with the data logger function. Via the micro-USB interface, the data can be easily transferred to a computer and processed without the need of additional software.

Protective armoring

• The protective armouring with two electrode holders guarantees safe working even in extreme environmental conditions at all times. The stand attached to the back of the housing can be used conveniently as a hanger or belt clip.

Additional features

• The range of functions is completed by the status display for the rechargeable NiMH batteries, the self-diagnosis of the sensors and much more.



Technical Data :

DisplayBacklit LCD with graphical displayData LoggerManual logger by keystroke. Automatic logger, cyclic, time interval adjustable.Power Supply3 NiMH-battery pack (AAA)Micro-USBAuto – OFFYesPortabilityPortableTemperature CompensationyesComplianceCERoHSWEEEProtection ClassIP 67Dimensions100 x 164 x 37 mmWeight310 g





Range :

Test parameterMeasuring RangeMethod No.Conductivity0 - 200 mS/cm  Oxygen0 - 500 %  pH-2 - 16  Redox-2000.0 - 2000.0 mV  Salinity0 - 70 g/kg  TDS0 - 200 g/l  Temperature-10 - 110 ° C
