Features - Easy to read large digital LCD screen displays heating temperature, rotation speed and timing- Speed range from 20 to 280 rpm- Large 5L water-oil heating bath with heating temperature range of RT to 180°C- Heating bath with precise temperature control and adjustable safety circuit- Designed a detachable operating panel allows remote control- Patented condenser(cooling surface 1,500 cm²) with excellent cooling effect- Motorized lift with quick-action, automatic release evaporating flask to top position in case of power failure- Adjustable final position recognition to protect operator and sample against breakage- Evaporating flask with an ejector, convenient to remove- Available with timer function to precise control processing- Chemical-resistant double PTFE system and patented pressure spring provide excellent sealing- PC can control and document all parameters via USB

Specifications:

Voltage [VAC]

100-120/200-240

Frequency [Hz]

50/60

Power [W]

1400

Motor Principle

DC brushless motor

Speed Range [rpm]

20-280

Speed Display

LCD

Reversible Direction of Rotation

Yes

Heating Temperature Range [℃]

RT-180

Heat Control Accuracy [℃]

±1

Heat Output [W]

1300

Temperature Display

LCD

Lift

Motor

Stroke [mm]

150

Timer

Yes

Timer Display

LCD

Time Setting Range [min]

1-999

Overall Dimensions [ D×W×H mm]

465×457×583

Weight [kg]

15

Permissible Ambient Temperature [℃]

5-40

Permissible Relative Humidity

80%

Protection Class acc. To DIN EN60529

IP20

USB

Yes

Standard configuration

Model

Descriptions

RE-5PRO

Rotary Evaporator with one set of glassware vertical (1000ml)

Optional items

Cat. No.

Descriptions

Volume

Size

18300117

Evaporating flask

100ml

NS 29/32

18300118

250ml

NS 29/32

18300119

500ml

NS 29/32

18300120

1000ml

NS 29/32

18300121

2000ml

NS 29/32

18300107

Receiving flask

100ml

KS 35/20

18300108

250ml

KS 35/20

18300109

500ml

KS 35/20

18300110

1000ml

KS 35/20

18300111

2000ml

KS 35/20

18300094

Connector

/

NS 29/32, NS24/29

18300095

/

NS 29/32, NS19/26

18300096

/

NS 29/32, NS14/23

18300093

Foam brake

250ml

NS 29/32

18100998

Vapor tube

/

NS 29/32
