SPECIFICATIONS :

 Bio Safety Type: 70%Re-Circulation, 30%Exhaust Through HEPA

Cleanliness: ISO CLASS 5 or CLASS 100 or M 3.5

Area Velocity at Grill: 90 20 FPM

Construction:Models available in 18 gauge (1.2 mm) stainless steel 304 ( Internal & External ).

HEPA Filter: HEPA Filters down to 0.3mic. particulate at an efficiency of 99.997% duly tested on

• DOP aerosol method
• SIZE: 1no – 915 X 610 X 69 at Supply/Equivalent
• SIZE: 1no – 610 X 305 X 68 at Exhaust/Equivalent

Noise level: 65 DB measured from filter face.

SEMI HEPA Filter:

• HEPA Filters down to 0.3mic. Particulate at an efficiency of 50% duly tested on DOP aerosol method
• SIZE: 1no – 610 X 610 X 68 at Section/Equivalent

Work Top: Perforated Work SS-304 Top with Train Dray

Front Sash: Sliding Door with Counter weight

Accessories: GAS / AIR cock – 01 No. 2.DOP Port

Electrical: ON/OFF Panel – (BL/UV/FL)

• Diffused Fluorescent Light – 36W to maintain 800lux – 1No. (Make: Philips)
• U V light with Hour meter – 30W – 1No – (Make: Philips)
• Auxiliary Socket: 15 Amps – 1 No.

Pressure Gauge: 1No. Magnehelic Gauge ( Make: Omicron )

Power Supply: 230 V, 50Hz , Single Phase
