SPECIFICATIONS

• Block Capacity :0.2mlx25wells + 48mlx16wells

• Block Temperature Range :0°C ~ 99.9°C

• Block Heating Rate :3°C/s

• Block Cooling Rate: 2°C/s

• Block Uniformity :≤ ± 0.3°C

• Block Accuracy :≤ ± 0.3°C

• Mode of Temperature Control: Sim-Tube & Block Mode

• Ramping Rate Adjustable 0.1°C ~ 3°C

• LCD Large-size Blue LCD

• Max. No. of storable programs  125 Typical Programs

• Max. No. Of Cycle; 99

• File Named :Yes

• Temp. Increment/Decrement: 0.1 ~ 10°C

• Time Increment/Decrement : 1 ~ 60s

• Auto Restart  :Yes

• Hold at 4°C Forever

• Auto Pause: Yes

• Running Time Display :Yes

• Hot Cover Temperature :105°C

• Height of Cover Seamless :Adjustable

• Hot Cover Auto Shut-Off :Yes

• Dimension （LxWxH): 267x220x253mm

• Net Weight :6.8kg

• Wide Power Supply Range: 110V±10%, 220V±25%, 50/60Hz


GRADIENT SPECIFICATION

• Gradient Accuracy≤ ± 0.3°C

• Column Uniformity ≤ ± 0.3°C

• Temp.Range for Gradient No 30°C -99.9°C

• Temp. Differential Range No 1°C -30°C

• Wide Power Supple Range 170~270V，50/60HZ
