WALK IN STABILITY CHAMBER
Product Details :
CONSTRUCTION
- Pre-fabricated modular panel type construction with PUF insulation to be assembled on site with floor panels having extra reinforcement to sustain the movement and sample load inside the chamber.
- The inner working chamber is water & vapour tight high-grade stainless steel.
- Chambers are provided with effective air circulation system, heating & cooling systems and humidity generator system.
- Multi-pane vacuum sealed observation glass window to view the samples without disturbing the test condition & human safety.
- Heavy duty solid stainless steel duly electro polished wire mesh type trays are provided which are easy to clean, time & efforts saving, also adjustable for convenience, along with detachable racks with adjustable angles.
CONTROL SYSTEMS
- 7″ HMI with TFT LCD Colour touch screen with password protection for all parameter actual status monitoring of utilities like Sensor, Heating & Cooling System, Humidity System.
- Rotronic make 4-20mA sensors for better accuracy.
- PLC with auto tuning facility for accurate control of temperature and humidity conditions.
- Data Storage unit facility to transfer the data to software via Ethernet for web based online remote monitoring with Date, Time, SV, PV, Door Open / Power On / Off remarks. Direct report printout provision from HMI.
ALARM & SAFETY
- Temperature deviation & RH deviation Alarm,
- Power Failure Alarm,
- Continues open door alarm,
- Very High Temperature & RH Safety cut off,
- Low water level cut off,
- Auto change over Facility for RH Generator & Cooling System.
SOFTWARE (21 CFR PART-11 COMPLIANCE)
- Log data, Event data, Audit Trail data, E-Records & E-signatures, Graphical analysis & Data acquisition.
| Technical Specification | ||
|---|---|---|
| Temperature Range | 20 ℃ - 60 ℃ | |
| Humidity Range | 40%RH - 95%RH | |
| Accuracy | +0.2 ℃ & +2.0% RH | |
| Uniformity | +2.0 ℃ & +3.0% RH | |
| Test Suitable for | 25 ℃ & 60% RH, 30 ℃ & 65% RH 40 ℃ & 75% RH, 30 ℃ & 75% RH | |
| Specially designed chambers for Low Humidity conditions such as 25 ℃ 40% RH, 40 ℃ 25% RH, 30 ℃ 35% RH | ||
SPECIAL FEATURES :
- Special door lock is provide which can opened from inside even if locked from outside.
- Door operation with password Access for Particular USER having the event log. Door open ENTRY USER:-XYZ & Door open EXIT USER:-XYZ in software.
- Person trapped cut off facility in chamber.
OPTIONAL FEATURES
- Stand by Cooling System
- Stand by Humidity System
- Scanner (8 Temp. + 8 RH for Online Monitoring Purpose)
- Mobile Alert System
- Security Alarm System
- Chiller System
MATERIAL OF CONSTRUCTION :
| Models | Material of Construction | |
|---|---|---|
| Interior | Exterior | |
| STD | S.S.304 Dull Finish | G.I Powder Coated |
| GMP | S.S.304 Dull Finish | S.S.304 Dull Finish |
| CGMP | S.S.316 Dull Finish | S.S.304 Dull Finish |
SIZES :
| Models | Capacity (in ltrs.) | Dimensions (W X D X H) | No. of Trays | |
|---|---|---|---|---|
| Internal (mm) Width Depth Height | External (mm) Width Depth Height | |||
| GMP-WSC2550L | 2550 | 1600 X 840 X 1900 | 1760 X 1000 X 2060 | 10 |
| GMP-WSC3000L | 3000 | 1600 X 940 X 2000 | 1760 X 1100 X 2160 | 10 |
| GMP-WSC6000L | 6000 | 2000 X 1500 X 2000 | 2160 X 1660 X 2160 | 20 |
| GMP-WSC8000L | 8000 | 2000 X 2000 X 2000 | 2160 X 2160 X 2160 | 24 |
| GMP-WSC10000L | 10000 | 2000 X 2500 X 2000 | 2160 X 2660 X 2160 | 30 |
| GMP-WSC12000L | 12000 | 2000 X 3000 X 2000 | 2160 X 3160 X 2160 | 30 |
| GMP-WSC16000L | 16000 | 2000 X 4000 X 2000 | 2160 X 4160 X 2160 | 40 |
Note: Other size of walk in stability chamber are available on request.
