WALK IN ENVIRONMENT TEST CHAMBER

Product Details :

MODEL: MKSI-143-SERIES

We hold expertise in manufacturing and supplying and exporting a superior quality range of Environmental Chamber. M.K. Scientific Instruments Environmental Chamber specially designed for drying environment of plant and animal growth, determination of di-electric strength, proof ness of packed materials, insulation testes of electrical components and many other tests requiring an atmosphere of controlled temperature & humidity. M.K. Scientific Instruments as an experienced manufacture in INDIA.

CONSTRUCTION :

• Double walled
• Inner Body: Inner chamber made of Stainless steel.
• Outer Body: outer chamber develop using high grade mild steel with powder coated finish. This coating keeps safe the unit from rust and normal scratches.
• Insulation between inner & outer wall with polyurethane foam (PUF) to reduce running costs.
• Temperature Range: The temperature can be controlled from 10°C to 60°C ± 2°C and humidity 55% to 95% ±5%.
• Temperature Controller: The Temperature is totally microprocessor based P.I.D. or Digital Temperature Controller cum Indicator controlled for accurate temperature rating.
• Compressor: Hermetically Sealed Air Cooling Compressor (CFC Free).
• Air Circulation: Forced convection system through use of blowers & motors that provides for superior mixing as well as strong dispersion.
• Shelves: Stainless steel perforated/wire road shelves adjustable and sliding.
• Door: Door with synthetic rubber gasket & Door has a glass viewer window.
• Heater: Tubular U type air heater.
• Power: Power input to be 220-230 Volts AC, 50/60 Hz fitted with Indian plug.

TECHNICAL SPECIFICATIONS:-
