Indoor Air Quality Monitor

Product Specification

Brand	Particles Plus
Model Name/Number	5301-AQM
Operating Temperature	41 to 104 Degree Fahrenheit (5 to 40 Degree Celsius) / 20% to 95% non-condensing
Dimension	5.22" x 2.25" x 9.13" (13.3 x 5.7 x 23.2cm) includes barb fittings
Standard	ISO 21501-4 and JIS B9921
Warranty	2 year limited warranty. Extended warranties available.
Storage Conditions	32 to 122 Degree Fahrenheit (0 to 50 Degree Celsius) / 98% non-condensing
Power	110 to 240VAC 50/60Hz universal in-line power supply
Sample Time	1s to 99h
Weight	4lb (1.8kg)
External Surface	Stainless steel
Instrument Calibration	Recommended minimum once per year. Gases, temperature and humidity sensors field calibratable.
Standards	ISO 21501-4 and JIS B9921
Alarm	Alarms on counts for all particle sizes, low battery, sensor failure, environmental sensors and flow
Communication Modes	Ethernet, USB. (Optional) Wireless 802.11 b/g, RS485 or RS232.
Audible Alarm	Adjustable built-in alarm
Custom Size Channels	Calibration for custom size channels available
Number of Channels	6
Filtered Exhaust	Internal HEPA filter
Internal Vacuum Pump	Internal pump with automatic flow control
Printer	(Optional) External thermal printer available
Display	4.3" (10.9 cm) WQVGA (480x272) color touch screen
Calibration	NIST traceable
Log Interval	Minimum 1s with no hold time, maximum 99h
Count Modes	Real-Time Meter and graph, cumulative/differential count/m3 and count/ft3, and mass concentration
Resolution	.00000003mg/m3
Light Source	Long life laser diode
Aerosol Concentration Range	0.01 to 20,00Mu g/m3
Flow Rate / Accuracy	0.1CFM (2.83LPM) / +/- 3%
Size Channels v	Factory calibrated at 0.3, 0.5, 1.0, 2.5, 5.0, 10.0Nu m variable binning

Product Description

Product Details:-

• The Particles Plus 5301-AQM and 5302-AQM Remote Air Quality Monitor measures and displays particle mass concentrations for PM1, PM2.5, PM5 and PM10 including temperature, relative humidity, CO2 (and TVOC in the 5302-AQM). This wall- mounted instrument is the most versatile remote air quality monitor available for fixed installations.
• The advanced power management and the industry’s first sleep mode, allows for long intervals between samples over extended and unattended operations. The AQM Series can easily integrate into a building automation and facility monitoring system via Ethernet, USB or (optional) Wireless 802.11 b/g, RS485 or RS232.
• The 5301-AQM and 5302-AQM reports and displays 6 user-selectable particle size channels, as well as Carbon Dioxide (CO2), temperature, and relative humidity. The instrument monitors PM1, PM 2.5, PM5, PM 10 (and any other PM size value the user specifies) with an easy-to-use Channel Management control panel. The instrument also monitors flow, sensor status, date of last calibration, serial number, laser on-time, and date of manufacture for easy maintenance and warranty management. The remote monitor operates using a long-life internal 0.1 CFM pump.
• View data and generate environmental reports real-time on screen, via printer or USB key, through the versatile output options, or export to Particles Plus® Instrument Management Software during monitoring system or network failure. Particles Plus® instruments can be controlled and monitored remotely via web browser from any PC, tablet or smartphone supporting up to 20 concurrent user sessions.
• The 5301-AQM and 5302-AQM particle counter stores 45,000 time-stamped particle count and environmental data records for redundant protection in the event of a monitoring system or network failure. The AQM Series mass concentration mode approximates density in μg/m³ and PM (particle matter) allowing for density and refractive index corrections to ensure accuracy. All Particles Plus® counters meet ISO 21501-4 and JIS B9921. These instruments ensure compliance with an on-board pulse height analyzer.


Features:-

• Stores up to 45,000 sample records
• Connect using Ethernet, USB or (optional) Wireless 802.11 b/g, RS485 or RS232

• Static or dynamic IP address (DHCP) connects to a local network or the Internet
• Seamless integration into a facility monitoring system with MODBUS RTU, ASCII or TCP
• Internet of Things JSON output allows for cloud based data storage and retrieval

• Included software permits remote operations, data management, diagnostics and more
  Displays and externally prints information with optional printer
• Internal audible alarm with user selectable thresholds for all environmental parameters

• Easy configuration and transferable from instrument to instrument
• User friendly field calibration with single or dual point offsets for all sensors

• Remote diagnostics allows for remote service investigation through the Internet
• Long life laser diode technology
• Lightweight stainless steel enclosure
