Pharma Refrigerator

Product Details :

Features :

• Double walled unit having two individual Chambers with separate controller (Upper & Lower)
• Inner & outer made of stainless steel 304 with matt finish.
• High grade CFC free Poly Urethane Foam PUF insulation provided to minimize the heat loss.
• Upper Chamber of the unit can be used as Freezer having Temperature Range up to – 20° C
• Inbuilt hermetically sealed CFC free Refrigeration System provided with Eco — friendly Refrigerant.
• Frost free unit with automatic defrost system.
• Temperature Accuracy: + 1° C
• Temperature Uniformity: + 3° C
• Stainless Steel Perforated Tray is provided for placement of samples
• Lower Chamber having Temperature Range 2° C to 8° C
• An Individual robust compressor with Condensing unit provided for fast achieving of Set Temperature.
• Individual Front opening door for each chamber with silicon gasket and door handle with lock and key
• Full length inner Glass door with Aluminum Powder coated frame provided for viewing of samples without disturbing inner chamber temperature
• Temperature Accuracy: + 0.5° C
• Temperature Uniformity: + 1.0° C
• PLC based Temperature controller
• 2 line LCD digital display with tactile key
• RTD — PT — 100 Sensors for accurate measurement and monitoring of temperature having resolution of 0.1° c
• Safety devices for temperature over shoot and under shoot along with audio & visual alarms.
• Communication with PC through LAN (Ethernet).
• Unit works on 1 phase 230 volts Ac 50 Hz
• This unit is design to meet ICH guidelines and all other regulatory norms
• Fulfill all requirements of WHO, US-FDA, MHRA & other audits
• It is an ideal unit to study Long Term Test, Accelerated, Intermediate and NMT tests in pharmaceuticals industry
• Pre — fabricated stainless steel made PUF insulated panels
• Unit is easy to install without any major hassle and ready to use in short span of time
• Unit delivers precise accuracy and uniformity of temperature and humidity
• In — built safety devices and corresponding indicators for over & under shoot of temperature and humidity
• Audio visual alarms generated for temperature and humidity deviation OR in case of any malfunction
• Hermetically sealed “CFC” free Refrigeration System is provided with Eco — friendly refrigerants for cooling. In built stand by cooling system provided with auto change over facility
• Newly designed boiler and water reservoir tanks provided for generating steam to maintain humidity in chamber
• Stainless steel made perforated trays with adjustable racks and runners
• Front opening door with vacuum glass window for viewing of samples and specimens without disturbing inner temperature and humidity
• Working manuals, test reports and certificates along with its traceability & |Q, OQ, & PQ protocols will be provided
• Calibration and Validation will be provided as per the protocol.

Technical Specifications

• PLC based Controller
• High quality 4 — 20 mA electronic Sensors
• Digital display having resolution of 0.1° C & 0.1 % RH visibility for accurate measuring of temperature and humidity
• Precise Temperature Control Accuracy + 0.2° C
• Best Uniformity of Temperature + 1.0° C
• Precise Humidity Control Accuracy + 2.0 % RH
• Best Uniformity of Temperature + 3.0 % RH

Temperature & Humidity Range

• 25° C & 60 % RH
• 30° C & 65 % RH
• 40° C & 75 % RH

Optional :

• Temperature Scanner 4 points (1in built + 3 optional Sensors)
• Common Software NIVDAS
• Remote Alarm System.
