Parameters

 WBC  Lymph#  Mid#  Gran#  Lymph% Mid% Gran% RBC HGB HCT MCV
 MCH MCHC RDW-CV RDW-SD PLT MPV PDW PCT and Histogram for
 WBC, RBC, PLT

 Principle

 Electrical resistance for counting and SFt method for HGB

 Sample Volume

 Prediluted blood Whole blood:

 20µl 9-20µl(option)

 Throughput

 < 1 minutes per sample

 Memory

 35,000 results

 Performance:

 Perameters           Precision CV%

 WBC(10/L)              2.0%

 RBC                         1.5%

 PLT                          4.0%

 MCV(fL)                   0.5%

 HGB(g/L)                 1.5%

 Display

 Large color LCD, displays all parameters result with histogram of WBC, RBC and PLT Resolution: 640x480

 Menu

 Count, Sample mode, Review, Quality control, System setting, Reference value,  System service, Calibration, Copyright,  Shutdown

 Alert

 25 sets of alert message

 Input/Output

 USB(keyboard, mouse, flash disk), Rs 232, parallel

 Print

 Graphic thermal printer with various printing format, optional external printer

 Operating Environment

 Temperature: 18-30°C Humidity: 10%-90%

 Power Requirement

 AC110-240V, 60/50Hz, 2A

 Dimension

 400mm(L) X 400(W) X 460mm(H)

 Weight

 24Kg
