Rainfall Station

Product Details :

EE-RS-01 Rainfall Stations are highly sophisticated monitoring & logging of intrinsic rainfall conditions and othe optional parameters according to your requirements. Application areas include agriculture, hydrology, ecology and meteorology. For any sort of customized application, E&E Solutions can give assistance to select the best blend of sensors, data logger and accessories accordingly

Optional Tools and Materials

• 12-volt | 7.2Ah lead acid battery to be used as backup power supply.
• Carpenter’s level to level the anemometer base.
• Electric drill with 3/16” (4.8 mm) and/or #29 (0.136” or 3.5 mm) drill bits to drill pilot holes.
• Electric tape if mounting the anemometer on metal mast or pipe.
• 2 stainless steel hose clamps if mounting the anemometer on pipe with diameter Greater than 1 1/4” (32 mm).
• Standard switch box if mounting the console with the wires running inside the Wall.
• Medium Phillips screwdriver if mounting the console on a wall.

Tools and Material needed for Installation

In addition to the enclosed components, you will need the following tools and materials to

complete the installation. Please be sure you have everything you need before proceeding with

the installation.

• Cable clips or weather resistant cable ties—with screw holes or other means for mounting.
• Small and medium-sized screwdrivers.
• Hammer.
• Small adjustable wrench.

Optional Accessories

The following accessories are designed for use with the Weather Station EE-RS-01.

• Rain Collector enables you to measure daily and accumulated rainfall. Separate models measure rainfall in either 0.25 mm increments.
• RS Software which integrated in the mother board, to log the data through Data Logger and generates reports and graphical displays of your weather data in excel.
• Sensor Mounting Arm, A single-location mounting option for your sensor.
• Bird Spikes protects the Rain Gauge from avoiding the birds to sit over the Aerocone. Which avoids litter in the Tipping Bucket.
• IP65 under IEC529 rating Ingress protection Junction Box-Enclosure Provides upgraded protection against radio frequency interference (RFI), electrostatic discharges (ESD), Water proofed and power surges that can come through sensor wires.
• Extension Cables Extends cable length for total cable runs of 80-140 feet (24-42 m) sensor to console. Order the 4-Conductor Extension Cable [in lengths of 40 feet (12 m) or 100 feet (30 m)]. for use with the anemometer, external temperature sensor, Rain Collector.
• Junction Box Cables Order a Standard 8-Conductor Cable for greater flexibility in the placement of your console. Comes in lengths of 25, 50, and 100 feet (7.6, 15.2, and 30.4 m)
