Model Sedimentation Tank Apparatus

Product Details:
description; The apparatus is designed to demonstrate the hydraulic characteristics and settling efficiencies of a model settling basin. The apparatus consists of a Sedimentation Tank in which the water is fed by overhead tank (available in user laboratory and not in scope of supply) at constant flow rate and is measured with the help of a rotameter. A complete unit for slurry circulation in sedimentation tank also accompanies the set-up including a sump tank for slurry, a feed pump for slurry. Flow rate of slurry entering the sedimentation tank is metered by suitable device. An accurate dye injection system is provided to inject the known volume of dye in the sedimentation tank. In sedimentation tank a weir is fitted which facilitate to the entry of well mixed slurry of known concentration in sedimentation tank uniformly.
• experimentation/learning objectivies;
• To measure the sediment removal efficiency and relating this to the hydraulic characteristics of a sedimentation tank
utilities required;
• Water Supply: 25 LPM at 1 Bar.
• Electricity Supply: 1 Phase, 220 V AC, 50 Hz, 5- 15 amp combined socket with earth connection. Earth voltage should be less than 5 volts.
• CaCO3 5 kg, Laboratory Grade.
• Digital Balance, Cap. 2500 gm, LC 0.01 gm.
• Colorimeter with 7 Narrow Band Pass Filters covering wavelengths 450 to 750 mm.
technicvcal details;
• Sedimentation Tank Material : Acrylic Size : 1000 x 400 x 200 mm
• Rotameter for Water Flow Range : 2 – 22 LPM (approx). Quantity : 1 No.
• Flow Meter for Slurry Flow Range : 0.2 – 2.0 LPM (approx). Quantity : 1 No.
• Sump Tank Material : PVC/SS Capacity : 120 Ltrs. Quantity : 1 No.
• Feed Pump : Compatible Capacity for slurry circulation.
• Control panel comprising of: Standard make On/off switch, Mains Indicator etc.
• An ENGLISH instruction manual consisting of experimental procedures, block diagram etc. will be provided along with the Apparatus.
• The whole set-up is well designed and arranged on a rigid structure painted with industrial PU Paint.
