Laser Welding machine Forza 160

Laser Welding machine Forza 160

Versatility of modulating power and speed in a nicer looking cabinet and improved reliability with added features:

  • color touch-screen display for an easier access to working parameter and better machine-to-operator interfacing/messaging fully displaying basic working parameters power, time, frequency of repetition, spot size; and by the joystick inside the welding chamber
  • memory cells to record permanent working settings for later use
  • preset pulse-shaping programs for LASER-welding alloys with special metallurgic characteristics
  • halogen light adjustable by dimmer
  • argon-gas supplied coaxially to the LASER-beam over targeted object
  • large integrated sealed circuit for cooling the flash-lamp specifically devised for longer LASER-welding sessions
  • by experience, the flash-lamp will last for at least 5 million pulses
  • thanks to its reduced size and weight, this unit is easy transportable



Applications Of CLW – 100DT/ 60DT

  • Weld  precious metals easily, including platinum, titanium, gold, silver & palladium
  • Repair perfect antique jewelry
  • Repair the frames without having to remove the stones
  • Repair watches & other components, even the glasses
  • Weld filler materials using the elements & lets you clear , crisp & with no need to clean up
  • Repair fusion defects such as porosity or fractures, only in those areas of the welding filler wire


  • Technical Data
MODELfoRza - 160DT
Max Pulse-Power and Duration160 at 20ms
Peak Pulse - power8Kw
Avg Pulse - Power85 W
Frequency of Repetition0.5 to 30 Hz
Spot size0.2 to 2.0 mm
Microscope10x a 45 binoculars and cross hair pointer by leica
Pulse-shaping Program6, Preset
Programmable memorycells 99
Weight40 kg
Dimension (W x D x H)70 x 50 x 50 cm
