Ion Exchange Apparatus

Product Details
Description
The set up consists of two glass column packed with Anion and Cation exchanger resin upto suitable height. The layer of glass wool is placed on bottom and top of the resin bed. The feed is allowed to enter from the bottom of first column and comes out of the top, which is again passed through the second column is same fashion. A digital conductivity meter measures the conductivity of liquid coming out of the second column. Flow rate of water is measured with the pre-calibrated rotameter. A tank with FHP pump with flow control valve and by-pass arrangement is provided for feed circulation
• Experimentation/Learning Objectives To deionise water to make it soft and to determine the exchange rate and saturation point.
Utilities Required
• Electricity Supply: Single Phase, 220 V AC, 50 Hz, 5-15 Amp. Combined socket with earth connection. Earth voltage should be less than 5 volts.
• Floor Area: 1.5 m x 1 m.
• Required Chemicals & Laboratory Glassware.
• Required analyzing equipments as per the system to study.
Technical Details
Column (2 Nos.) : Material Borosilicate Glass / Stainless Steel Dia 55mm, Length 500mm approx. (For Anion & Cation)
• Water Tank : Material Stainless Steel, Capacity 25 Ltrs.
• Feed Circulation : FHP Pump, Mashbow/Standard make
• Flow Measurement : By Rotameter, Eureka make
• Piping : Stainless Steel and PVC
• Conductivity Measurement : Digital Conductivity Meter
• Control panel comprising of : With Standard make On/Off switch, Mains Indicator etc.
• An ENGLISH instruction manual consisting of experimental procedures, block diagram etc. will be provided along with the Apparatus.
• The whole set-up is well designed and arranged on a rigid structure painted with industrial PU Paint
