Construction Details:

•     Designed as per ICH guidelines to meet, WHO and USFDA requirement
•     Fulfills storage conditions of 25° C - 60% RH, 40° C - 75 % RH, 30° C - 65% RH, 25° C - 40% RH, 30° C - 35% RH
•     Temperature Accuracy : ± 1.0° C
•     Temperature Resolution : 0.1° C
•     Humidity Range : 30% RH To 80% RH,
•     Humidity Fluctuation : Maximum 3% RH
•     Chamber illumination : With 2 or 4 LED lights for lesser power consumption
•     Compressor Watts : 1.5 KW
•     Dry Heater Watts : 2.0 KW
•     Wet Heater Watts : 3.0 KW
•     Overall Power Consumption : 2.5 KW Per phase (For 3 - phase connection)
•     Power consumption : 7.0 KW (For single phase connection)
•     Capacitance type Humidity sensor enables direct display of RH and temperature
•     (ASI - PLC) Application Specific Integrated Programmable Logic Controller with Touch screen HMI for precise control of temperature and humidity parameters - fully protected with password
•     Colour graphic HMI System
•     Auto change over to standby systems through PLC - Change over from Main set to Redundant Set and vice Versa
•     Multipurpose Temperature and humidity logger with printout facility
•     In - built data logger for selected number of channels (4, 8, 12, 16, 32) within the LCD colour Graphics controller
•     ASIC system with HMI having capacity of inbuilt storage upto 2 GB - 38,00000 storage readings (Nearly unlimited storage) - this is the controller storage capacity
•     21 CFR compliance software - part 11 USFDA guidelines
•     10 - 20 different Humidity chambers can be connected to EIE - 21 CFR Compliance software
•     Highly ergonomic door handle with unique key lock
•     Built up with 80 mm puff Insulation for maximum thermal protection.

Specifications:

•     Temperature: -25c
•     Refrigerant: R404A
•     Size: Large
•     Structure: Knock Down
•     Use Nature: Production

Additional Information:

•     Item Code: EIE-106RHMI
•     Port of Dispatch: Ahmedabad Airport
•     Production Capacity: 100 Pieces Per Year
•     Delivery Time: 3-4 weeks after receipt of firm order
•     Packaging Details: Strong plywood packing with robust foundation
