Grain Size Analysis Pipette Met For Testing Labhod for Soil

Product Details :

Grain Size Analysis Pipette Met For Testing Labhod for Soil Testing Lab - This is for the determination of the sub sieve particle distribution in a soil sample by mechanical analysis. An analysis of this kind expresses quantity the proportions by weight of the various sizes of particles present in the soil. It is recommended as a standard procedure to use dispersion agent to avoid flocculation. The apparatus consists of a sliding panel which moves up and down by means of a screw allowing Anderson pipette fixed to it to be raised or lowered vertically. A sedimentation tube is held by a laboratory clamp provided on the stand below the pipette. The depth of immersion is measured by a scale graduated in mm at the side of the sliding panel. Supplied complete with Anderson pipette 10ml. At the side capacity made from glass, and a sedimentation tube also of glass of 500ml capacity and 50nos. Test form pads. ACCESSORIES & SPARES : 1) Sedimentation Pipette (Anderson pipette) 25ml. 2) Sedimentation tube 100ml 3) Sedimentation pipette 10ml 4) Sedimentation tube 500ml 5) Test forms pad of 50.
