LyoEpic PRO
Product Details:
LyoEpic Pro has the same production characteristics as Coolvacuum’s pilot equipment LyoLab, but reduced dimensions.
Its compact design and a wide variety of control options make LyoEpic Pro the best choice for companies or laboratories that wish to manufacture small batches to be scaled up to larger production facilities.
LyoEpic Pro, made of AISI 316 L, is equipped with a PRO* chamber that allows automatic vials stoppering. LyoEpic Pro features a fluid recirculation system for heating and cooling of the trays.
Model | LyoEpic PRO | |||||
|---|---|---|---|---|---|---|
Shelf area | 0.12 m² | |||||
Shelf dimensions (W x D) | 200 x 300 mm | |||||
Nº of shelves | 2 + 1 | |||||
Shelves clearance | 70 mm | |||||
Chamber material | Stainless steel AISI 316L | |||||
Condenser capacity | 12 kg | |||||
Vacuum pump output | 12 m³/h | |||||
Condenser temperature | -85 ºC | |||||
Shelves temperature range | de -50 ºC a +70 ºC | |||||
Heating power supply | 180 W | |||||
Overall dimensions (W x D x H) | 540 x 630 x 1.655 mm | |||||
Peso | 250 kg | |||||
