WATER BATH RECTANGULAR D0UBLE WALLED
Product Details:
Double walled inner chamber made of Stainless Steel outer made of S.S/Mild Steel duly painted/ Powder Coated. Top has 75 mm holes with concentric rings. Temperature range up to 99oC. Accuracy ± 1oC thermostatically Controlled fitted with Neon Lamp; indicator, main switch and workable on 220 Volt 50 Hz. A.C.
TECHNICAL SPECIFICATIONS & ORDERING INFORMATIONS

Internal Dimensions (LX W X D) 300 x 250 x100mm 350 x 400 x100mm Capacity 8 Ltr 15 Ltr No. of Holes 6 12 Holes Dia. 75 mm 75 mm Heating Load 1.0 KW 2.0 KW T emperature Controlled with hydraulic type Capillary Thermostat T emperature Range From ambient to 90oC T emperature Accuracy ± 1oC. or better Heater Protection By Stainless Steel Perforated cover

OPTIONAL FEATURES

ELECTRONIC DIGITALCONTROLLER Temperature controlled by Micro processor based temp. indicator cum controller. STIRRING ARRANGEMENT stirrer fitted with stainless steel shaft.
