REFRIGERATED WATER BATH WITH CIRCULATION SYSTEM
REFRIGERATED WATER BATH WITH CIRCULATION SYSTEM
Product Details:
Inner chamber made of Stainless steel, outside mild Steel Painted/ Powder Coated. The gap between the two is filled with glass wool. Heating by immersion heater placed in the chamber and cooling by sturdy refrigeration unit duly controlled by Electronic Digital Temperature Controller Cum Indicator from 5°C to 90°C with Sensitivity of ± 2°C. Front panel is 0provided with indicator lamp individual switches for heating and cooling purpose.
Internal Dimensions (L X W X D)
250 x 250 x 250mm
500 x 250 x 250mm
Approx. Capacity
17 Ltr.
32 Ltr.
Approx. Heating Load
2.0 KW
2.5 KW
Top Lid
Double walled insulated
Temperature
Controlled by microprocessor based digital temperature indicator cum controller.
Temperature Range
5oC to 90oC
Temperature Accuracy
± 1oC.
Temperature Display
Digital LED with set value (SV) & process value (PV).
Temperature Sensor
RTD (Pt-100)

OPTIONAL FEATURES

Temperature control by
By profile (Micro Programmable) controller.
Communication Port
With interface and data cable to download data to your PC
Voltage Stabilizer
Servo or Automatic Stabilizer to regulate in coming voltage
