Water Still

Product Details :

Water Still-

Features :

1.Abundant Output. The still provides, 4 Litres/hr. Of distilled water produced through a power input of 3 KW by a Chromium Plated heater housed in a horizontal Borosilicate Glass Boiler (Pyrex Brand Borosilicate Glass.)

2.Distilled output is cool ensured by a high efficiency condenser. Temperature of distillate 25 deg C - 40 deg C tested for ambient room temperature of 30 deg C.

3.Provision for Wall Mounting.

4.All Units Carry CE Marking.

Distillate Quality

• Ideal for General Laboratory Use- Capable of Producing Pyrogen Free Water.

Water Still

Construction:-

• The Stand is powder coated for long rust free operation.
• Heater is a 3KW Chromium plated heater fitted with a thermostat, which shuts off automatically in case of water supply failure.
• The boiler & condenser are designed for high efficiency and provided with threading for easy plumbing of condenser.
• Boiler is provided with Teflon screw cock for insitu cleaning of the water.
• All plumbing connections to the equipment are made via screw Thread Connections.

Specifications

Dimensions     :           (W x D X H)

PH 4                :           50cm x 15 cm 15 cm x 45 cm

Weight            :           6 kg. Approx.

Electricals        :           220/240V, 50/60Hz. Single phase.

Power              :           3 KW Heater

Water Supply  :           Min. Flow rate 1 Litre/min.

Min Pressure   :           3 p.s.i (0.2 x 105 NM-2)
