Vertical Autoclave
Product Details:
A versatile, electrically heated sterilizer under saturated steam of Adjustable pressure of 10 to 20 psi.double walled construction with boiler & steam jacket made of thick stainless steel and gap is filled with high grade glass wool to bring the temp.loss to a minimal level.The outer chamber is made out of thick mild steel.The lid is made of thick stainless steel plate (joint less) or gunmetal plate and can be sealed by a joint less neoprene rubber gasket by wing nuts through hinged bolts by engaging slotted lugs on rim of the cover. Provided with dial pressure gauge, air/ steam release cock, spring loaded safety valve adjustable to any required point from 10 psi to 20 psi with accuracy + 3 psi.A drain cock has also been provided.A double safety valve has also been provided along with inlet.Supplied complete but without dressing bins.

Dia x Depth	load Capacity (approx.)	Chamber Size
22ltrs.	2KW	250x450mm
40ltrs	3KW	300x500mm
50ltrs	4KW	400x550mm
78ltrs	5KW	400x600mm
98ltrs	5KW	450x600mm
152ltrs	6KW	550x750mm
