Transistor Characteristics Apparatus
Objective : Input & Output Characteristics of Common Emitter PNP & NPN Transistors Input & Output Characteristics of Common Base PNP & NPN Transistor.
Features :Instrument comprises of Two DC Regulated Power Supplies 0-10VDC/150mA & 0-1VDC/150mA, four round meters for voltage & current measurement, one PNP & one NPN Transistor mounted behind the panel, connections of Supplies & Transistors brought out at 4mm Sockets.
