Theory Of Machine Lab
Product Details:
To verify the relation simple pendulum
To verify the relation of compound pendulum & to determine the radius of gyration
To study radius of gyration of bi-filar suspension.
To study the undamped free vibration of spring mass system
Undamped torsional vibrations of double rotor system
To study the damped torsional vibration of single rotor system and to determine the damping co-efficient
To study the forced damped vibration of spring mass system
TOM-102 Camanalysis Apparatus:
To plot the n-q (Follower displacement Vs Angle of rotation) curves for different cam follower pairs
The follower bounce can be observed by using a stroboscope (Optional) & effect of follower weight on bounce can be studied
To study the effect of spring compression on bounce
The tests can be repeated by changing compression springs, follower weights and cam speed
