Stepper Motor Control Unit

Features :

Includes commonly used Industrial grade servo motor and servo drive Extension module for use with PLC Training Rack

Description :

Stepper Motor Control Unit is designed to study and demonstration of the principle and working of a industrial servo motor with provision for direct PLC interface is provided. It consists of the servo motor and the servo drive. The Trainer is housed in an elegant cabinet with a well spread intelligently designed multicoloured layout on the front panel. Multicoloured test points are provided at various stages to observe the waveforms and voltages. It is strongly supported by a comprehensive instruction manual complete with theory, operating details and machine code program.Detailed Operation and Maintenance Manual is provided along with the trainer.

Specification :

• Can be plugged into the training rack
• The control unit includes: Recognition of the rotating direction of a motor RPM regulation Regulating torque Homing Positions Ramps
