Stability Chamber Microprocessor Control
ALPHA CHEM- 954 Stability Chamber Microprocessor Control
These are Microprocessor Controlled Chambers with soft touch keyboard for fast and accurate setting of various parameters. Just set the temp., humidity & time and the system runs automatically. All the parameters are digitally displayed and reproducible.
Special Features:
- Temp. accurately controlled through microprocessor based controller
- Automatic On / Off of the compressor according to need of process to reach & maintain the set values
- Chamber illumination with fluorescent or ultra violet lights
- Audio Visual alarm warning of temp. variation
- User’s friendly Microprocessor Design/Operation
- Features of Environmental Test Chambers :
- Humidity accurately controlled through
- microprocessor controller in addition to temperature
- Direct display of humidity in % RHQ. Audio visual alarm warning of low water levels & door opening
- Humidity : 40% to 95% ± 3%
Technical Specification :
Capacity in ltr. | Temperature Range |
170 lit. / 6 cft | 4°C to 60°C ± 1.0°C |
285 lit. / 10 cft | 4°C to 60°C ± 1.0°C |
340 lit. /12 cft | 4°C to 60°C ± 1.0°C |
170 lit. / 6 cft | Ambient to 70°C ± 1.0°C |
285 lit. / 10 cft. | Ambient to 70°C ± 1.0°C |
340 lit./ 12 cft | Ambient to 70°C ± 1.0°C |
Optional:
1. Chart Recorder weekly
2. RS-232C interface available for humidity control through personal computer
3. Digital temp. indicator-cum-controller with computer data logger
4. Cyclic timer for regulating illumination conditions
Automatic Voltage Stabilizer 3 KVA
