Spring Tester
Product Details:

Brand	TENSTRON
Automation Grade	Digital Manual
Capacity	50 kgf, 180 mm
Frequency	Compression and Tension
Least Count	1 gram, 1 micron
Material	MS
Measuring Range	0-50 kgf
Operating Temprature	Ambient
Power Source	12V DC Adapter
Voltage	12V DC
Country of Origin	Made in India
Patent	Design Patented by TENSTRON Pvt. Ltd.

TENSTRON® Spring Compression and Tension Load Testing Machine (TENSTRON-SPR04-50kg) is having ultra high accuracy load and deflection/tension test mechanism with side hand wheel. The design is patented by TENSTRON Pvt. Ltd. (INDIA). This testing machine have accuracy of 1 gram throughout the full scale of 50 kg. with accuracy of 1 micron throughout 180 mm of travel. The machine is capable of giving actual deflection values within the full range of load i.e., from 0 kg to 50 kg. The load and deflection both readouts are in two units i.e., kg. and N, mm and inch respectively. Which can be selected through a push button on the go. The high accuracy ball screw is used with combination of high quality slide rods and slide for smooth displacement with anti back lash mechanism which provide the system a high stability and repeatability along with minimized operating frictions.
