Model No.

IG-294

 Optical System

Single Beam, Grating 1200 lines/mm

 Wavelength Range

190~1000nm

 Spectral Bandwidth

2 nm

 Wavelength Accuracy

1nm

 Wavelength Repeatability

<=0.2 nm

 Photometric Accuracy

0.5%T

 Photometric Repeatability

0.2%T

 Photometric Range

0 - 200%T, - 0.3 - 3A

 Stray light

0.15%T

 Stability

±0.0002A/h @500n

 Baseline Flatness

±0.002 A

 Noise

±0.001 A

 Wavelength Setting

Auto

 Light Source

Imported Deuterium & Tungsten lamp

 Display

128*64 LCD

 Detector Imported

Silicon Photodiode
