Model No.

L3-2375

Wavelength Range

190-1100 nm

Spectral Bandwidth

1 nm

Working Mode

T,A,C,E

Optical System

Double beam

Scanning Speed

Fast/ Medium/Slow

Photometric Range

-0.3 - 3.5 A, 0 to 220 %T

Wavelength Accuracy

+0.3 nm

Wavelength Reproducibility

< 0.10 nm

Photometric Accuracy

+ 0.3% T(0-100% T) +0.002 A(0-0.1 A)

Photometric Reproducibility

< 0.15 %T

Stray Light

< 0.1% T (Nal. 220nm, NaNO2 340 nm)

Baseline Flatness

+ 0.002 A

Stability

+0.001A (at 500 nm, after warming up)

Noise

+0.001A (at 500 rim, after warming up)

Detector

Dual Silicon Photodiode

Display

6 inches high light blue LCD

Power

220V + 10% AC, 50 Hz.

Dimensions

630 x 470 x 210 mm

Weight

26 Kg

Model No.

L]-2373 Research Model

Optical System

Double Beam (1200 Lines/mm Grating)

Mode

Basic/Quantitative/Wavelength Scan/DNA

Wavelength Range

190 to 1100nm

Scanning Speed

Fast/Medium/Low

Bandwidth

1nm

Wavelength Accuracy

+0.3nm

Wavelength Repeatability

0.2nm

Photometric Accuracy

+0.3 %T

Photometric Repeatability

0.2%T

Photometric Display Range

0-200% T. -0.3-3.0 A, 0-9999 C

Stability

0.001 A.h@ 500 nm

Baseline Flatness Noise

±0.001 A

Stray Light

< 0.05 % 220 nm. 360 nm

Data Output Port

USB

Printer Port

Parallel Port

Display

Graphic LCD (32D*240 Dots)

Lamps

Deuterium Lamp & Tungsten Halogen

Detector

Silicon Photodiodes

Packing Dimensions

790 x 590 x 370 mm (LxWxH) Approx.

Net Weight

26 Kg
