Solar Cell Characteristics Apparatus

Objective :



•  To plot the I - V characteristic curve of a solar cell
•  To observe the relationship of current, voltage and power in a solar cell, and to identify  the maximum power point, the short circuit current, and the open circuit voltage.
•    To evaluate fill factor of the solar cell



Features : One Solar Cell mounted in a plastic box, light source, two analog meters mounted on front panels, build in Two dial decade resistance box & wooden plank with 50cm scale.
