Small Oxygen Gas Plant
Product Details:

Oxygen Generator Capacity (Nm3/hr)	50 Nm3/Hr
Technology Used	Cryogenic
Purity Of Oxygen	99.7%
No. of Cylinders Filled In A Day	200 Jumbo Cylinders in a Day
Application	Industrial/Medical
Installation Time	25-30 Days
Brand	ING. LA. BOSCHI
Model No. / Model Name	UBPL-50
Type of Compressor	Screw Air Compressor
Automation Grade	Fully-Automatic
Design	Customized
PRODUCTION (M3/Hr)	50 M3/Hr
PRODUCTION Liters/Hour	58 Liters/Hour

Small Scale Oxygen Gas Plant(UB- 50 m3/hr) is fabricated with the latest cryogenic air separation technology. Being the top-class manufacturing company, we are known for providing oxygen machinery which is competitively priced. Having world-class engineering expertise, our company has gained the trust of customers by making oxygen gas plants that can generate oxygen with purity up to 99.7%. Our machinery is certified with ISO 9001:2015 and CE standards that guaranty high quality performance all across the globe. We cater to the requirements of small to large scale industries. The plants are made in capacities ranging from 20 m3/hour to 1000m3/hour. Customization is our forte as we have the know-how to make machinery as per the requirements of clients.
Our oxygen gas plant is based on the process of Linde & Claude, developed in 1930s, which has been improved many times.  Atmospheric air is taken inside the inlet of air separation plant which is then compressed.  Now, the air is directed into a cleanup system where impurities like moisture, hydrocarbons, carbon dioxide, etc. The air is passed through heat exchangers where it is cooled to extremely low temperatures. Here, the air is entered into a high pressure distillation column where oxygen is separated from nitrogen and other gases. It is further distilled to commercial specifications in the low pressure distillation column.
