Single Point Load Cell
Product Details:

Model	1510
Capacity	500 Kg
Material	Stainless Steel
Ingress Protection	IP68
Application	Industry
Features	High Accuracy & Precision
Load Cell Certifications	OIML, NTEP
Creep Error (30 minutes)	+/-0.03% FS
Accuracy Class	OIML R60 C3
Zero balance	+/- 1% FS
Maximum Safe Overload	150% FS
Recommended Excitation Voltage	5 to 15V DC
Input Resistance	400 +/- 10 Ohms
Output Resistance	350 +/- 5 Ohms
Insulation resistance at 50V DC	>= 1000 M Ohm
Compensated Temperature Range	-10 to +40 Deg C
Operating Temperatue Range	-20 to +70 Deg C

Model 1510 is a high accuracy single-point load cell ideally suited to industrial applications which undergo regular washdown, typically platforms, wall scales and other process weighing applications in the food industry.
Hermetically sealed against moisture, the all welded construction of the 1510 in combination with a polyurethane dual shielded cable, enables continuous operation in harsh environments while maintaining a high operating specification.
The two additional sense wires feed back the voltage reaching the load cell. Complete compensation of changes in lead resistance
due to temperature change and/or cable extension, is achieved by feeding this voltage into the appropriate electronics.
