Seam Welding

APPLICATION:

Spot welding, projection welding, cross wire welding, resistance heating, electro-brazing, With special attachments it is also possible to weld nonferrous material within certain limitions.

USERS:

Include – but are not limited to general engineering work-shop, makers of furniture, electrical instruments, containers, barrels and drums, telephone, radio communication devices, clocks, kitchen-ware,textiles machinery and spares automoblies-ancillaries,toys, air-conditions, refrigerators, motors, switchgear, etc.

STANDARD FEATURES – ALL MACHINES:

MAIN SUPPLY-415 Volts. Single Phase (2lines of 3 phase supply) 50 Hz.

AIR OPERATION:

Spring follow-double acting cylinder; Airline filter, lubricator, regular pressure gauge; Electric Solenoid Valve; Machine machanically capable of 125 operations/minute. ELECTRICAL – Foot Switch/Palm Button; Weld/No Weld Switch;Pressure Switch; Transformer in Class ‘F’ Insulation. provide with 8 current regulating taps between 55% and 100% output: Contrail circuits at less than 110 Volts. COLLING – By water with separate circuits for main Transformer, Secondary conductor and Electorder.die (in case of projection Welders) Thyristors. Each circuit to terminate in sight cup provide, wheel valves each circuit. PROTECTION – Transformer, Thyristors by themosate against water failure; Luminous overload indicator on panel.

ELECTRONIC CONTROLS :

Microprocessor based solid state Electronic Control with Thyristor Contact or unit.

SPECIAL FEATURES AVAILABLE ON REQUEST :

• Actuation – Hydraulic-Motor H Air Reservoir h RTap Change Switch h Refrigerated or closed circuit cooling h Voltage/Current compensation h Other Voltages, Frequencies
• Special Purpose machines for /Special application, or Non Ferrous metals or Stainless and other exotic Steels electrodes h Special Tolong for projetion Welding
• Special Locating jigs for Spot /Switch Welding h Geneva Index ablets h Automatic Feeders h Customer Ideas
