Sampling Outfit For 38 Mm Dia Specimens

Brand

Atico

Advanced technocracy inc. Is manufacturer, exporter & supplier of Sampling Outfit For 38 Mm Dia Specimen

For collecting undisturbed samples of 38 mm. dia. fr6m borrow pits or from larger size samples for unconfined compression test or triaxial shear test. The outfit consists of Sample extractor, screw type with a wire sample trimmer and Jarring link, for driving the sampling tube of 38 mm dia. An adaptor with locking screw for fitting the 38 mm dia. An adaptor with locking screw for fitting the 38 mm dia. sampling tubes to jarring link is provided. Following more accessories are supplied

Split mould 38 mm dia x 88mm long provided with quick release clamps.,

Split mould. 38 mm dia x 76 mm long..

Split tube, 38 mm dia x 150 mm long.

Sampling tube,38 mm dia x 200 mm long..
