SPILT TUBE FURNACE TWO ZONE

Melting Material	Copper
Material Loading Capacity	0-500 kg
Power Source	Electric
Type Of Furnace	Tilt

Product DescriptionFeatures:

• Heating Elements: Silicon Carbide, Coil type with end connection, easily replaceable.
• Inner Chamber: Ceramic Refractory / Board with heating elements placed on the top & bottom.
• Insulation: Ceramic Fibre.
• Construction: Tripple walled with air insulation on the outer side For Minimal Skin Temp.
• Body: Made of mild steel duly Powder Coated.
• Tube Material: Alumina (optional – Quartz)
• Tube Size: Inner Dia. = 90mm / Hot Zone length = 400 mm / Overall length = 1000 mm (With Alumina Tube & SS Couplers)
• Gas Purging: Ends of the tube have SS couplers with cooling attachment for purging of gases.
• Power Control: SCR unit (Phase Angle Thyristor).
• Temp. Control: Microprocessor based PID Programmable Controller
• (1 Prog. X 16 Segment). Dual display of Set & Actual Temp. with soft touch keys. With Thermocouple break. Protection & Cold junction compensation. CE mark to meet EMC regulations.
• Safety: Over current and Short Circuit Protection.
• Thermocouple break alarm

Additional Information:

• Item Code: 766
• Production Capacity: 90
• Delivery Time: 6 days
• Packaging Details: box
