SPARE PARTS FOR PSA NITROGEN GAS GENERATORS

Sequence Timers / PLC

The Sequence Timer, PT 130 is a multi channel and multi range instrument. Three basic timing range seconds, minutes and hour with a resolution of 0.01, 0.1 and 1 are programmable for both on time and off time. The 11.059 MHz quartz crystal gives an accurate timing range over the full scale. The timer has NO / NC output relay contacts rated at 6A 230 volts AC. The display is a 7 segment LED. It has a built in batch counter facility to count the number of cycles completed. The remote and front panel reset, hold function give easy operation. The timer is compact and of standard DIN size. It is available in the range of 4, 10, 18, 26, 34 channels.

Application

It is used in hydraulic press sequence control, for blending and storage silos in cement industry, for bag filters, dust collectors, tyre tube curing press, pot header in rubber industry and for machine tool sequence.
