Robot Model (4-axis)

Process Control Trainers

SPECIFICATION

The Robot Model (52320) gives provision to interface PLC with 4-Axis robotic arm to Pick and Place an object from one Position to another with help of PLC program and HMI.

Features
Controlled by PLC
Displacement in all 3 planes and 4-axis.
Capable to pick and place an object from one position to another.
Variable Jaw area to Pick objects of different shapes.
Object Lift movement height Selectable

Experiments
Study of level measurement using the concept of back pressure regulation.
Demonstrate the implicative use of pressure gauge as a level measurement (indirect measurement technique).
Dimensions
Control Panel: 1.5 Ft (L) × 1 Ft (W) × 1.5 Ft (H)
Pick & Place Platform: 1.5 Ft (L) × 1.5 Ft (W) × 2 Ft (H

Services Required
230V AC,1φ Supply.
