Pressure Gauge
Product Details:
Construction features dial size : 100mm & 150mm accuracy : 1% of full scale case & bezel (ip-65) : ss 304 snap action bayonet type movement : ss 304 pressure element : ss 316 ( ≤ 70 bar `c` type / > 70 bar coil type ) socket :SS 304 / SS 316 dial : aluminum white painted with 270 degree black scale marking pointer : al / brass, zero adjustment / micro zero adjustable pointer. window : acrylic glass blow out protection : black side st 0. 6 kg/cm2 over load protection : 125% of F. S. D. For ≤ 150 kg/cm2 115% of f. S. D. For > 150 kg/cm2 joints : argon arc welded. mounting : stem (bottom, panel mounting, flush panel (bracket type) scale range : vacuum & pressure up to 700kg/cm2 contact details : 380V AC/DC , 50 V A/30 watts, current not exceed 1 amp. contact type : magnetic single contact (1nos, 1nc) double (1 no+NC, 1nc+1no, 2 no, 2 NC) optional features : Diaphragm sealed with electrical contact available on request.  Lpd with electrical contact available on request.
