Paper Laboratory Crush Tester
Product Details:

Model	UEC-1026-A
Display Type	Digital
Voltage	220V
Brand	UEC
Frequency	Standard Load Range 0-200 Kg f (0-2000 N).
Medium	Electricity
Weight	34 Kg
Country of Origin	Made in India

The ring crush resistance of paper and paperboard is the maximum compressive force that a test piece will sustain without being crushed, the test piece being in the form of a ring standing on one end, and the force being applied to the other end under specified conditions. Crush Tester (Beam deflection method) motorized is operated with dial indicator and peak pointer
Load range: 0-50 , 0-100 Kg. Accuracy within 20% to 80% of the normal range of deflection Platen size 100 x 100 mm RCT sample holder and removable disc (08 numbers) for a thickness of 0.15 mm to 0.49 mm(supplied with main unit).
Platen size 100 x 100 mm.
