PN Junction or Zener Diode or LED Characteristics Apparatus
Features : Instrument comprises of two DC Power Supplies, two round meters to measure voltage & current, 2 PN Junction Diode, 1 Zener Diode & One Red LED mounted behind the panel and connections brought out at terminal/Sockets.
