PCB Design Kit
Product Details:
This consists of the design and material for designing 60 PCB's for a class of 30 students.PCB Design Kit consists of circuit scematics & the following :
a) Components such as Transistors, Diodes, IC's for dimensional purposes,.........50 Nos.
b) Copper Clad sheets cut to 6"x4" size........60 Nos.
c) PCB Drafting Stickers,Tapes................... 2mm,3mm
IC Pads...................8 Pins
Doughnut Pads.................. 5mm
Transistors pads etc. to make..................60 PCB's
d) Plastic films cut to 7"x5" size...................60 Pcs.
