Muffle Furnace
Product Details:

Country of Origin	Made in India
Brand	Jainco
Melting Material	Aluminium
Material Loading Capacity	100
Power Source Furnace	Electric
Type Of Furnace	Tilt
Type Of Model	Furnace

Operation Temperature:-  1100.C  ( 1200.C Max for short time). Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina fiber ceramic insulation. Three sides resistance wire coil for fast and uniform heating. Heavy duty double layer structure with cooling fan.  Lower temperature in outside case. 0.5" diameter observation window made of quartz glass allow user to see insider chamber during heating operation.  K type thermocouple installed for immediate use. Temperature controll unit can be separated from furnace , and make moving at easy. PID automatic control via current limiting phase angle fired the resistor , e.g. SCR ( Silicon Controlled Rectifier)     Sample size: 200x200x200mm (WxHBTI)Detailed Description:                                                                    Chamber size200x200x200mm(WxHBTI)Max.Temperature                          1200CWorking temperature1100CTemperature  accuracy+ 1.CTemperature controller30 segments programmable and auto controlHeating elementsNi-Cr wireVoltage220V 50HZ, single phasePower4kw
