Melt Flow Index Apparatus
Product Details:

• Melt Flow Index measures the rate of extrusion of molten resins, through a die of specified length and diameter, under prescribed conditions of temperature, load, and piston position in the barrel, as the timed measurement is being made.
• Melt Flow Index, per ASTM D-1238, measures flow rates of thermoplastics  by extrusion plastometer.

• P.I.D. temperature controller, RTD temperature probe and cast heater insure rapid heatup and stable constant temperature to the test sample.
• Digital display of setpoint and actual temperature quickly provide correct temperature information.

•  Thermo isolators separate electronic components from heat, providing more consistent test results and less potential for system failure.
• Optional equipment includes weight application and cutting device.

• Temperatur
• Controllers: P.I.D.
• Probe: RTD
• Range: (100o C - 350o C)

• Accuracy: < 0.2o C
• Option variable weights available, supplied with equipment 2.16 kg.
