UCI HARDNESS TESTER

Product Details :

High precision hardness tester TKM-459CE intended for quick measuring of metal items hardness in laboratorial, manufacturing and field conditions.

Device is intended for non-destructive testing of production quality in metallurgy, mechanical engineering, aircraft, shipbuilding, atomic industry, oil and gas industry.

Hardness tester functions by UCI method (Ultrasonic Contact Impedance).TKM-459CE controls hardness of following:

• Carbonaceous and structural steels
•  Items with surface-hardened layers such as cementation, nitride hardening, high frequency current hardening
•  Heat-proof, corrosion-proof, non-corrosive steels
•  Plated coating (chrome), overlaying
•  Items of complicated configuration

Exploitation advantages

• Stable readings independent from force and time of pressing.
•  Easy measuring in hard-to-reach areas.
•  Ultra-small control area (from 1 mm).
•  Control in slots and blind holes from 5 mm (not provided by rival devices).
•  Invisible print on mirror-surface.
•  Low sensitivity to the curvative of surface, thickness and weight of product.

Features of TKM-459CE

•  Impact-, dust- and water- proof housing.
•  Intuitive graphic interface.
•  Bright color graphic display allows working at below zero temperature and stays bright at any lighting.
•  Signalization of exceeding of prescribed readings threshold.
•  Unique system of statistic data processing and averaging of readings.
•  Fast adjustment of readings and programming of additional calibrations to basic scales by 2 or less standard blocks.
•  Flexible device memory for recording of readings and their analysis.
•  Programming of additional scales calibrations by 2 or less standard test blocks.
•  Fast programming of additional scales by 2 to 10 standard test blocks.
