MODEL DHV5 DIGITAL DISPLAY LOW LOAD VICKERS HARDNESS TESTER

Product Details :

Features :

• A High precision frictionless loading shaft mechanism and a high quality optical imaging system are adopted in this instrument. The steady test force has been ensured and the test accuracy is high.
• Angular displacement sensor technology and computer techniques are adopted and the automatic test procedure is realized.

Specifications:

• Measuring range: 5-3000HV
• Test force: 1.961, 2.942, 4.903, 9.807, 19.61, 24.52, 29.42, 49.03N (0.2, 0.3, 0.5, 1, 2, 2.5, 3, 5kgf)
• Magnifications of the measuring microscope: 500X, 125X
• Min. scale value of the measuring microscope: 0.025μm
• Max. height of test piece: 130mm
• Power supply: 220/110V AC, 50/60Hz
• Dimensions: 438 x 376 x 685mm
• Weight: Approx. 50kg

Main accessories

• Coordinate anvil: 1 pc.
• Thin shaft anvil: 1 pc.
• Thin plate anvil: 1 pc.
• Flat nose pliers: 1 pc
• Large V-notch anvil: 1 pc
• Small V-notch anvil: 1 pc
• Diamond pyramid penetrator: 1 pc.
