Brinell Hardness Testers
Product Details :
| Model Name/Number | ASI-3000 |
| Brand | ASI |
| Automation Grade | Manual |
| Hardness Scale | HBW |
| Country of Origin | Made in India |
- This machine is designed for Brinell Hardness measurement on steel & other ferrous materials & also on non-ferrous materials like Brass, Bronze, Aluminum, etc. The material can be cast, forged or rolled & the shape can be flat, round or irregular.
- This machine is specially used in production testing. Its stability & unique design of a floating fulcrum lever system ensure high accuracy & dependability.
- he load application system is of dead weight type combined with mechanical lever system. The supporting hydraulic system is for initial lifting of load before each test & damping the load application system for smooth application of load.
- Test loads from 500 to 3000 kgf in steps of 250kgf.
- The height X Throat is 380 X 200 mm.
- Indentation measurement by Brinell Microscope of 25 X Magnification.
- Manual / Optical / Computerized type Brinell Hardness testing machines are also available.
- Accuracy conforms to IS:2281-2005 & BS:240.
Technical Specification :
Load (kgf) | 500 to 3000 in steps of 250 |
Initial load (Kgf) | NIL |
Maximum test Height x Throat (mm) | 380 x 200 |
Maximum depth of elevating screw below base (mm) approx. | 180 |
Machine height (mm) approx | 1250 |
Size of base (mm) approx | 400 x 740 |
Net weight (Kg) approx | 400 |
Drive motor (hp) | 0.5 |
Mains supply | 3 Phase, 415V, 50 Hz, AC |
Standard Accessories :
Flat testing table dia 200 mm | 1 No |
V Groove testing table dia 70 mm for round jobs of dia 10 to 80 mm | 1 No |
Ball holder dia 5 mm | 1 No |
Ball holder dia 10 mm | 1 No |
Test Block HBW 5/750 | 1 No |
Test Block HBW 10/3000 | 1 No |
Allen key set | 4 -pieces |
Tungsten Carbide ball dia 5 mm | 1 No |
Tungsten Carbide ball dia 10 mm | 1 No |
Indentation Measurement | 1 Book |
Brinell Microscope | 1 No |
