Brinell Hardness Tester
TECHNICAL PARAMETERS
Model
DM-HBE-3000M
Brinell scale
HBW2.5/62.5 HBW2.5/187.5 HBW5/125 HBW5/750
HBW10/100 HBW10/250 HBW10/500 HBW10/1000 HBW10/1500 HBW10/3000
Test force
62.5kgf(612.9N) 100kgf (980.7N) 125kgf (1226N) 187.5kgf (1839N 250kgf (2452N)500kgf (4903N) 750kgf (7355N) 1000kgf (8907N) 1500kgf (14710N) 3000kgf (29420N)
Min. measuring unit
0.005mm
Hardness value read
Digital LCD
Total amplification
20X
Specimen max. height allowed
230mm
Size
550×210×750mm L×W×H
Weight
120kg
Dwell time
5 60S
Power supply
AC220V + 5%, 50~60 Hz
Standard accessories
20X measuring objective 1 piece, Φ2.5 Φ5Φ10mm harden alloy indenter 1 piece, standard hardness block 2 pieces, big, medium and “V” test table each 1 piece, power cable 1 piece, accessory box 1 set, dust-proof cover 1 piece, manual instruction,
Request
Callback
Model | DM-HBE-3000M |
Brinell scale | HBW2.5/62.5 HBW2.5/187.5 HBW5/125 HBW5/750 HBW10/100 HBW10/250 HBW10/500 HBW10/1000 HBW10/1500 HBW10/3000 |
Test force | 62.5kgf(612.9N) 100kgf (980.7N) 125kgf (1226N) 187.5kgf (1839N 250kgf (2452N)500kgf (4903N) 750kgf (7355N) 1000kgf (8907N) 1500kgf (14710N) 3000kgf (29420N) |
Min. measuring unit | 0.005mm |
Hardness value read | Digital LCD |
Total amplification | 20X |
Specimen max. height allowed | 230mm |
Size | 550×210×750mm L×W×H |
Weight | 120kg |
Dwell time | 5 60S |
Power supply | AC220V + 5%, 50~60 Hz |
Standard accessories | 20X measuring objective 1 piece, Φ2.5 Φ5Φ10mm harden alloy indenter 1 piece, standard hardness block 2 pieces, big, medium and “V” test table each 1 piece, power cable 1 piece, accessory box 1 set, dust-proof cover 1 piece, manual instruction, |
