Light Duty CNC Lathe Machine
Capacity Data | Light Duty Lathe Machine |
---|---|
Full Machine Size (LXWXH) | 1200 X 600 X 500 |
Machine Centre Height | 8 inch |
Max. Turning Dia | 100 mm |
Spindle HP with VFD | 3 HP |
AC Servo Drive & Motor | 1.3 Nm |
Spindle Bore | 38 mm |
Spindle Speed | Max. 3000 |
Spindle Nose | A25 |
Repeatability | 0.04µ |
Lubrication | Automatic |
Ball Screw (Hiwin) | Ø 25 |
CNC Controller | Mach3 / Siemens* |
Coolant | Automatic |
4 Station Square Tool Turret | 130 Optional |
Hydraulic Chuck | Ø 165 Optional |
Max User | College Trainer / Toolroom Production |
