Level Measurement Trainer

Features :

The apparatus is designed to demonstrate level measurement using Level Transmitter. The setup consists of a level sensor mounted inside a transparent tank. Water can be filled in the tank laboratory tap connection. The sensor output is displayed on the digital indicator. A scale on the tank reads the water level for comparison with sensor reading.

Experimental Capabilities:

• To study level measurement using a level sensor.
• Centrifugal Pump and Sump Tank (Optional)
• Electrical Switches and Indicators
