Blood Bank Refrigerator
Product Details:
Special Features
- The strong construction outer chamber is made of light steel, which has been treated in the past and finished with a powder coated paint for permanent finish.
- To maintain uniformity of temperature in the chamber, equipped with durable coaxial blowers for forced air circulation back to triple wall.
- The outer front double-walled door is untouched and with no magnetic tape mounted for air tight closing without any temperature loss, which is available with lock and arrangement.
- Door operated illumination lamp is fitted inside the chamber for easy visibility.
- Enables inspection and monitoring of internal chamber samples without disturbing the temperature of a full-view internal placby-glass door process.
- High grade PUF INSULATION between outer and inner chamber for minimal thermal losses.
- The compressor / condensing units marked by ISI are cooled by CFC free and R-134 by an eco-friendly refrigerant in the air circulation path, the fine tube evaporates lie.
- The temperature is controlled by the electronic digital temperature indicator co-controller which fits with the audio visual alarm in which the battery is included with the back which is more than the allowed tolerance in the case of fluctuation. The unit has also been installed as a safety device with a door operated alarm and power supply failure alarm. To prevent the stored blood bag from spoiling.
- Drawers are provided for accommodating blood bottles or Blood bags.
- Caster wheel mounted for easy portability.
- Supplied with cord and plug.
- Operating Voltage: 220 Volts AC (50/60 Hz).
Model No. | RSI/BB-40 | RSI/BB-85 | RSI/BB-165 | RSI/BB-215 |
Approx Volume (Ltr) | 40 ltrs | 85 ltrs | 165 ltrs | 215 ltrs |
Blood Bags Capacity | 24 | 50 | 110 | 200 |
No. of Shelves | 2 | 2 | 3 | 3 |
Internal Chamber | Inner Chamber Made of Stainless Steel 304 | |||
External | GI Powder Coated | |||
Temperature | Preset at 4°C ± 1°C | |||
Temp. Controller | The PID digital temperature indicator co-controller with microprocessor is equipped with alarm feature, with specially designed deviation alarm, pre-set temperature, door open alarm and power failure alarm. | |||
Temperature Alarm | High 60C & low 20C, Audio Visual Alarm | |||
Display: | LED Display | |||
Relay | Solid state electronic relay with protective heat sink. | |||
Battery Backup | Facility is provided | |||
Illumination | By 8 watts Fluorescent Lamp | |||
Air Circulation | By forced convection system | |||
Insulation | By High density PUF insulation | |||
Operations | Nearly silent operation with ultra-low vibration | |||
High Voltage Protection | Through automatic voltage stabilizer (Optional) | |||
Power Supply | 220/230V AC, 50/60Hz |
