LCR Resonance Circuit with Built in Oscillator
Objective : To Plot Frequency Vs. Current Characteristics of LCR circuit when connected in series or in parallel.
Features :Instrument comprises of 3 Resistances, 3 Capacitors & 1 Inductance connected inside & connections brought out at Sockets. 2 AC moving coil meters to measure voltage & current. Built in Sine Wave Oscillator 100Hz - 100khz is provided.
