LCR Resonance Apparatus
Brand | ASICO |
Usage/Application | Laboratory |
Model Name/Number | AE 249 |
Type | Analog |
Color | gray |
Power Supply | used with function generator |
LCR Resonance Apparatus (AE 249 )
Objective : To Plot Frequency Vs. Current Characteristics of LCR circuit when connected in series or in parallel.
Features :Instrument comprises of 3 Resistances, 3 Capacitors & 1 Inductance connected inside & connections brought out at Sockets. 2 AC moving coil meters to measure voltage & current.
